UHF Mount on metal Tag for containers and asset tracking

UHF Mount on metal Tag for containers and asset tracking
UHF Mount on metal Tag for containers and asset tracking
UHF Mount on metal Tag for containers and asset tracking
UHF Mount on metal Tag for containers and asset tracking
UHF Mount on metal Tag for containers and asset tracking

UHF Mount on metal Tag for containers and asset tracking

The UHF Mount on metal Tag, easy to relocate, metal mount RFID tags for high temperatures.The UHF RFID mount on metal tag can be used to manage the certification and approval data of new containers and asset tracking, as required by international standards, safety regulations and customer needs.

The UHF Mount on metal Tag, easy to relocate, metal mount RFID tags for high temperatures.The UHF RFID mount on metal tag can be used to manage the certification and approval data of new containers and asset tracking, as required by international standards, safety regulations and customer needs.

Feature:

▶100% Complies to RoHS

▶Passed high temperature test at200°C (392 °F) for 6 hours

▶Passed200°C hot oil chamber test for 6 hours

▶Passed85°C/95% RH humidity test for 168 hours

▶Passed 200*Cycles b/w ‐45°Cand85°C

▶Passed free falling 1kg iron ball impact test from    1.5M height

▶Passed drop& topple ‐IEC 60068‐2‐31

▶Passed vibration ‐IEC 60068‐2‐6

▶Passed 1kg iron ball impact test from 1.5M height

▶Passed chemical stress test with sulfuric acid, NaOH, salt water, etc

▶Passed ingression test (IP67)

▶EPC Class1 Gen2 with ALIEN Higgs3

▶ISO 15693 NXP ICODE SL2 (Titan Biscuit)

▶Best read perform with similar size on‐metal tags

▶Encoding and barcode printing service provided

Specification

Working Frequency

860~960MHZ

Dimension

  50*56mm, 9mm thickness

Protocol

ISO-18000 6C (GEN2 EPC)

Chip

Aline H3 ,IMPINJ M4 or customize

Storage Capacity

EPC: 96 bits, User Memory 512bit

Working temperature

-20℃ ~ 70℃

Material

Industrial-grade Plastic ( ABS)

Reading Range

3m (Handheld) & 12m (Fixed ) --- (It depends on actual application environment and

readder)

Life

100,000 times, 10 years

Waterproof:

IP67

Mount:

Screwing/ Riveting/ Adhering

Operation mode

passive

FAQ:

1.  What about the warranty period

Two years without natural and man-made damage. We guarantee no worries for the after sale.



2. What about the delivery time?

Once we got payment or deposit, 5-7 working days for producing 1000-80000 pcs tags.



3. What about the sample testing?

Free Sample (Existing sample) for testing before client place full order.



4. what is your company ?



◆ Applications

● Container management

 ● Device Management

● Asset management

 ● Transport Tracking

 ● Energy Industry

 ● Manufacturing and Logistics

  ● Metal material management ( Tool and Rental Equipment )
