Mifare 1k card mifare classic card mifare classic 1k card supplier

These PVC smart mifare 1k card  are perfect for creating custom-printed smart ID cards for use as employee badges or government ID credentials.

Each mifare classic  card is made of 100% PVC, and features internal MIFARE Classic® 1K  technology that can be programmed to allow the mifare 1k card to open doors, process payments, capture data and more.

These mifare classic 1k cards are standard CR80/credit card size, measuring 2.13" x 3.38".

The nxp mifare classic 1k cards operate at a frequency of 13.56 MHz and are ISO/IEC 14443 compliant.

Mifare classic 1k card Cards can be customized using a standard PVC ID card printer.

Composite Mifare 1k s50 smart cards with a HICO magnetic stripe are also available .

The MIFARE Classic 1K card from NXP operates at 13.56 MHz wireless frequency, according to the ISO 14443A standard, and contains 1K bytes of read/write memory that can be used for multiple applications. This version of the MIFARE Classic 1K card has a unique 7 byte (56 bit) chip serial number/ID, instead of the older 4 byte (32 bit) variety.

MIFARE Classic cards typically operate at a distance of up to 10cm depending on the power provided by the RFID reader.

Supplied as blank white PVC cards to ISO standard. Our mifare classic cards contain only original NXP chips and use premium quality materials and production methods in order to ensure maximum performance, reliability and compatibility.

mifare 1k card specification

MIFARE‚ RF Interface (ISO/IEC 14443 A)

Contactless transmission of data and supply energy (no battery needed)

Operating distance: Up to 100mm (depending on antenna geometry)

Operating frequency: 13.56 MHz

Data transfer: 106 kbit/s

Data integrity: 16 Bit CRC, parity, bit coding, bit counting

Anticollision

Typical ticketing transaction: < 100 ms (including backup management)

EEPROM

1 Kbyte, organized in 16 sectors with 4 blocks of 16 bytes each (one block consists of 16 byte)

User definable access conditions for each memory block

Data retention of 10 years

Write endurance 100.000 cycles

Security

Mutual three pass authentication (ISO/IEC DIS 9798-2)

Individual set of two keys per sector (per application) to support multi-application with key hierarchy

Unique serial number for each device
