D.O RFID TAG company is a RFID card manufacturers & factory, professional RFID card manufacturers , NFC tags suppliers and RFID Wristband company in shenzhen china for 15 years — Source Quality Products and Enjoy Efficient Service.
D.O RFID Tag Manufacturer with 14 years experience of manufacturing Antennas,D.O RFID Tag manufacturer can produce the UHF inlay tag perfectly with the drawing provided.RFID tags have been increasingly popular in the field of advanceditem identification technology. Though universal adoption of RFID smart label is taking time, many retail giants including Wal-Mart and Carrefour promote the use of RFID tags to replace traditional barcodes as a more effective method of item tracking. Beyond the retail sector, other examples of RFID usage are in swipe-less credit cards and for logistics purposes.
The number of uses for RFID UHF labels is nearly endless across a huge variety of industries. While there is a wide range of chips for RFID inlays, there is an extensive array of RFID inlay/antenna patterns as well, including the paperclip, squiggle, and dogbone designs. Most of our tag s antennas are tailor made for a specific use. Contact us today to customize your RFID inlay/antennas.
| Alien UHF Inlay | |||
| Picture | Model number | IC Type, Size, Protocol | |
 | Alien 9610 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 44.45*10.33 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9613 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 12*9 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9620 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 27*9.7 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9627 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 30*45 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9629 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 22.5*22.5 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9630 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 70*9.5 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9730 | IC Type: | Alien Higgs-4 |
| Antanna (mm): | 70*9.5 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9634 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 44*46 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9640 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 94.8*8.2 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9740 | IC Type: | Alien Higgs-4 |
| Antanna (mm): | 94.8*8.2 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9654 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 93*19 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9662 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 70*17 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Alien 9762 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 70*17 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
| Impinj UHF Inlay | |||
| Picture | Model number | IC Type, Size, Protocol | |
 | Impinj B41 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 22*8 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj B42 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 22*8 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj B43 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 24*24 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj B44 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 24*24 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj B45 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 20*20 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj E41 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 94*8 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj E41b | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 95*8 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj E41c | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 95*8 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj E42 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 68*19 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj E44 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 105*6 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj E51 | IC Type: | Monza 5 |
| Antanna (mm): | 95*8 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj E52 | IC Type: | Monza 5 |
| Antanna (mm): | 68*14 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj E53 | IC Type: | Monza 5 |
| Antanna (mm): | 44*18 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj F43 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 26*16 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj H41 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 30*46 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj H42 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 44*44 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj H47 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 44*44 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj J41 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | ф12 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | Impinj J42 | IC Type: | Monza 4D、4E、4QT |
| Antanna (mm): | 15*8 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
| Junmp UHF Inlay | |||
| Picture | Model number | IC Type, Size, Protocol | |
 | JMP 1206 | IC Type: | QSTAR-35 |
| Antanna (mm): | 12*6.39 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | JMP TS01 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | 95*3 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | JMP 1819 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | ф36 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
 | JMP 1820 | IC Type: | Alien Higgs-3 |
| Antanna (mm): | ф36 | ||
| Protocol: | ISO18000-6C/EPC GEN2 | ||
